Aten US7220
Aten US7220 Aten US7220 Aten US7220 Aten US7220 Aten US7220

Aten US7220

3x Thunderbolt 2.0, 3x USB3.1 A, 2x USB2.0 A, eSATA, RJ-45, HDMI, DC12V , 90W, 97.5 x 57 x 191.9 mm, 780 g

US7220

Out of Stock

Save up to 2% online

Require Project Pricing?

Click here to email your parts list and we will send you a quote

The US7220 Thunderbolt 2 Sharing Switch is a dual-computer docking station with full KVM functionality for your workspace. You can share Thunderbolt devices, a dual-monitor setup and USB peripherals through a single cable, directly to two computers.

The US7220 enables two Thunderbolt 2- enabled computers to share peripherals with ultra-high 20 Gbps data transfer rates. As a KVM sharing switch it allows you to easily switch the keyboard, video, mouse and peripherals between two computers with the push of a button. With the ability to daisy-chain up to five Thunderbolt devices, the US7220 connects up to 11 peripherals including Thunderbolt monitors and video capture devices; plus USB drives, printers, high-definition cameras, keyboards, mice and more.



The ATEN Thunderbolt 2 Sharing Switch is the ideal choice for those who want the flexibility of laptop computing – with the performance, sharing and high-definition/dual-monitor capabilities of a full workstation.
Depth57 mm
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Height191.9 mm
MaterialAluminium
Maximum resolution3840 x 2160 pixels
Operating temperature (T-T)0 - 40 °C
Weight780 g
Width97.5 mm

US7220.pdf

Aten US7220 Data Sheet

Download (1.09M)
