Aten CS1922
Aten CS1922 Aten CS1922 Aten CS1922 Aten CS1922

Aten CS1922

4x USB3.1 B, 4x DisplayPort, 8x Mini Stereo Jack, 2x USB3.1 A, 88 x 270 x 55.5 mm, 910 g

CS1922

Out of Stock

Save up to 2% online

Require Project Pricing?

Click here to email your parts list and we will send you a quote

The ATEN CS1922 2-Port USB 3.0 4K DisplayPort KVMP™ Switch provides the latest innovations in desktop KVM switching technology for the increasing demand of higher video quality and transfer speeds on modern computers. The ATEN CS1922 offers an unprecedented performance of delivering 4K resolution, the next generation USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates and enhanced user-friendly operations.



As a KVM switch, the CS1922 allows users to access two DisplayPort computers from a single USB keyboard, USB mouse and monitor console. Doing so with ease, the CS1922 provides three convenient switching methods – using front panel pushbuttons, mouse, or hotkeys for flexible access to any computer connected to the installation.



The unique independent switching feature allows the KVM control to focus on one computer while the USB peripheral focus is on another computer. This eliminates the need to purchase a separate USB hub or stand-alone peripheral sharer – such as a print server, modem splitter, etc.



With its rich feature set, the CS1922 is designed to surpass all requirements in graphic design, animation, and video-editing applications. Such as CAD/CAM (computer aided design/manufacturing). The CS1922 allows you to share the audio from each of the connected computers. HD audio transmitted by DisplayPort would offer you a different experience.
Depth270 mm
Height55.5 mm
MaterialMetal,Plastic
Maximum resolution4096 x 2160 pixels
Operating temperature (T-T)0 - 50 °C
Weight910 g
Width88 mm

CS1922.pdf

Aten CS1922 Data Sheet

Download (1.84M)
