Axis COMPANION CUBE LW
Axis COMPANION CUBE LW Axis COMPANION CUBE LW

Axis COMPANION CUBE LW

1/3” RGB CMOS, 2.8 mm, F2.0, 110 deg, 61 deg, M12 mount, IR, 0.25 lux 50 IRE F2.0, 0.05 lux 40 IRE F2.0, 1/28000s - 1/5 s 50 Hz, 1/32500s - 1/5s 60 Hz, 1920 x 1080, 320 x 240, AAC-LC 8/16 kHz, 82 dB-SPL, 802.11 a/b/g/n @ 2.4/5 GHz, 512 MB RAM, 256 MB, 10 m

0892-002

Out of Stock

Save up to 2% online

Require Project Pricing?

Click here to email your parts list and we will send you a quote

- Indoor full HD IR wireless network camera

- Wireless communication with support for a/b/g/n

- High video quality in HDTV 1080p and 2 MP resolution

- Built-in IR illumination for surveillance in total darkness

- WDR to handle scenes with complex light conditions

- Built-in microphone, mini-speaker and PIR motion sensor

- Bracket for wall and corner mount

- AXIS Companion Card 63 GB included

- 3 year warranty



Easiest set-up for 1-2 camera solution



AXIS Companion Cube LW together with AXIS Companion Card 64 GB makes a self-contained recording solution. Through wireless communication with AXIS Companion software and apps, this is the easiest set up for a smaller surveillance solution.



Please note!

AXIS Companion IP cameras are supported only by AXIS Companion video management software and mobile apps for iOS and Android devices.



Smart design for indoor surveillance



AXIS Companion Cube LW features high quality video in HDTV 1080p/2 MP resolution and WDR. It comes with IR illumination, day/night functionality, PIR motion sensor, microphone and mini-speaker. The camera connects over wireless LAN (IEEE 802.11a/b/g/n) or wired Ethernet. It supports Wi-Fi Protected Setup™ with push button configuration. AXIS Companion Cube LW is optimized for edge storage and with AXIS Companion Card 64 GB included it is a self-contained recording solution. Axis Zipstream technology allows even high quality video to be recorded effectively. AXIS Companion Cube LW is supported only by AXIS Companion video management software and mobile app.
CertificationEN 55032 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, RCM AS/NZS CISPR 32 Class B, KN24, KN-35\n\nEN 300328, EN 301489-1, EN 301489-17, EN 301893,\nFCC Part 15 Su
Connectivity technologyWireless
Depth37 mm
Form factorCube
Frame rate30 fps
Height106 mm
Maximum resolution1920 x 1080 pixels
Minimum illumination0.05 lx
Mounting typeWall
Night vision distance10 m
Operating temperature (T-T)0 - 40 °C
Optical sensor size1/3 "
Placement supportedIndoor
Sensor typeCMOS
Video compression formatsH.264,M-JPEG
Viewing angle, horizontal110 °
Viewing angle, vertical61 °
Weight128 g
Width60 mm
Number of cameras1

0892-002.pdf

Axis COMPANION CUBE LW Data Sheet

Download (676.63k)
