Axis P1435-LE
Axis P1435-LE Axis P1435-LE

Axis P1435-LE

Outdoor-Ready, CMOS 1/2.8”, f=3–10.5 mm, F1.4, HDTV 1080p, Digital PTZ, WDR, 1 x RJ-45 10BASE-T/100BASE-TX PoE, IP66, NEMA 4X

0777-001

Out of Stock

Save up to 2% online

Require Project Pricing?

Click here to email your parts list and we will send you a quote

Compact and cost-effective HDTV surveillance for any light condition



With features such as Lightfinder and WDR – Forensic Capture, the bullet-style AXIS P1435-LE provides excellent image quality in HDTV 1080p resolution, even in complex light conditions. In addition, the camera supports Axis’ Corridor Format, pixel counter, remote zoom and focus, as well as P-Iris control. The day and night camera is ideal for 24/7 video surveillance, in exposed outdoor areas such as parking lots and service stations, and for general indoor surveillance purposes wherever a compact camera is needed.



Excellent image quality



AXIS P1435-LE with its varifocal, P-Iris lens provides excellent image quality at up to 60 frames per second. The P-Iris control provides optimal depth of field, resolution, image contrast and clarity.



Lightfinder and Wide Dynamic Range (WDR)





With Wide Dynamic Range – Forensic Capture, the camera provides perfectly balanced video quality in scenes with strong variations in light, while Axis’ Lightfinder technology enables outstanding image usability in poor light. The camera can seamlessly transition between handling WDR and low-light conditions.



Built-in IR-LEDs and OptimizedIR



AXIS P1435-LE offers OptimizedIR, Axis’ power-efficient LED technology that provides an adaptable angle of IR illumination. With OptimizedIR, the camera provides automatic illumination of a scene in complete darkness, in case of an event or when requested by a user. The improved IR LED illumination is perfect for discovering objects in a range of up to 30 meters (100 ft).



Edge storage and Zipstream



AXIS P1435-LE offers support for edge storage that makes it possible to record video directly to a storage such as a microSD/SDHC card, thereby creating a flexible and reliable video surveillance system. In addition, Axis’ Zipstream technology lowers bandwidth and storage requirements by an average of 50% without costly and complicated integration. Zipstream ensures that important details in the image get enough attention in the video stream while unnecessary data can be removed.



Ease of installation



AXIS P1435-LE has a compact, low weight casing and integrated bracket for wall or ceiling mount. To further facilitate installation, a wide range of mounting accessories are available. AXIS P1435-LE offers easy installation with remote zoom and focus for fine tuning of the picture from a computer. Power over Ethernet supplies power to the cameras through the network, eliminating the need for power cables and reduces installation costs.



I/O ports



The input/output ports can be used for simple notification to an alarm panel or control of a relay. The input is also ideal when using a PIR motion detector.
CertificationEN 55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 50121-4,\nIEC 62236-4, EN 55024, FCC Part 15 Subpart B Class B,\nICES-003 Class B, VCCI Class B, RCM AS/NZS CISPR 22 Class B,\nKCC KN22 Class B, KN24, IEC/EN/UL 60950-1,\nIEC/EN/UL 60950-22, EN 62471, IEC/E
Connectivity technologyWired
Depth260 mm
Ethernet LAN (RJ-45) ports1
Form factorbullet
Height132 mm
Housing materialPolycarbonate,Polyester
International Protection (IP) codeIP66
Maximum resolution1920 x 1080 pixels
Mounting typeCeiling/wall
Night vision distance30 m
Operating temperature (T-T)-30 - 60 °C
Optical sensor size1/2.8 "
Placement supportedOutdoor
Sensor typeCMOS
Supported network protocolsIPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP TM , SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Video compression formatsH.264,M-JPEG,MPEG4
Viewing angle, horizontal95 °
Viewing angle, vertical51 °
Weight900 g
Width132 mm

0777-001.pdf

Axis P1435-LE Data Sheet

Download (511.92k)
